SPECS

Specifications and Features:

• Rotating ball nut and fixed ball screw linear drive system

• Dual 1204 sized ball nuts with center drive pulley and ball screw

• Each set individually hand adjusted for minimum backlash and rolling resistance on the ball screw

• Highest accuracy and repeatability

• Lowest rotational mass of just 5 ounces

• Up to 4000 rpm

• Up to 600 inches per minute

• Sold together with power ball nut assembly and matched ball screw as a set

• 40 tooth center drive pulley

• For 3mm pitch, 9mm wide GT2 belts

• Dual oversized 37mm angular contact ball bearings for high load capacity and long life

• Twice the ball count and three times the ball diameter of standard 10mm thrust bearings

• 0.15748" lead per revolution

• Overall length of ball screw assembly: 2.75"

• For Nema 23 sized servos

• Custom mounting plates to accommodate your special requirements

ROTATING BALL NUT DRIVE SYSTEM
